Name: Bianchi T-Tronik T-Type Step-through Frame 43cm Grey
Brand: Bianchi
SKU: 214_sku
Price: 2399.99 USD
Availability: OutOfStock

Bianchi T-Tronik T-Type Step-through Frame 43cm Grey

Product Details

Brand: Bianchi

Motor Unit
1. Motor
  Shimano E6100, 250W, 60Nm
2. Battery
  417Wh integrated battery
Frameset
1. Frame
  T-Tronik T-Type Step-through ALU sizes: 43, 47 - 9x135 mm quick release dropouts - Post mount 160 disc brake type
2. Fork
  Suntour NEX-E25 DS 700C, 63mm travel, 1-1/8" HT,w/out 9x100 QR , minimum 160mm rotor, maximum 180mm rotor, 30mm stanchions
3. Headset
  FSA HST STbk 1-1/8" 44H-N10P
Drivetrain
1. Shifters
  Sram X5, 9sp
2. Rear Derailleur
  Sram X7, 9sp, max. 36T
3. Crankset
  Shimano CHAINRING, SM-CRE61, 38T FSA SMN E-Bike Forged Crankset - SMN / 170mm
4. Bottom Bracket
  included in the motor
5. Chain
  KMC e9S NPBK
Brakes
1. Brakes
  Promax, DSK-925
2. Rotor
  Promax DSK-925, 160mm, center lock
Wheels
1. Wheels
  EBIKE 650 TR 28" - ETRTO 622 x 23C, 32hole, height 18mm
2. RearHub
  Shimano, FH-TX505-8, 32H 8/9/10/11-SPEED,OLD:135MM,AXLE:146MM,QR:170MM
3. FrontHub
  Shimano, HB-TX505,32H OLD:100MM AXLE:108MM, QR:133MM
4. Tire
  Chaoyang E-Liner City 700x45C, 60tpi
Cockpit
1. Stem
  Velomann, 28,6 mm steerer ID Clamp, 31,8 mm
2. Handlebar
  Velomann 31.8/680mm, RISE 20MM, SWEEP 15°
3. Grips
  Herrmans GRIPset Oxy
Saddle
1. Seatpost
  Velomann, lenght 350mm for SM size and 400mm for MD, diam.31,6mm, 0mm seatback
2. Saddle
  Selle Royal
Accessories
1. Pedals
  VP black aluminum, axle 7mm, 113,5x110,5mm
2. Mudguards
  SKS PET Mudguards A60 S /28"
3. Kickstand
  Ursus, load 35kg
4. RearCarrier
  Racktime, 28", Max load 25Kg
5. FrontLight
  Herrmans Mr GO e-bike 6/12 V
6. RearLight
  Axa Juno e-bike 6/12 V
